SCP Series - Miniature Syringe Pump

100 µl, 500µl or 1000 µl syringe capacity

SCP Series - Miniature Syringe Pump

Description

This miniature syringe pump has dimensions of only 26 × 42 x L120 mm with integrated 2-phase stepper motor.

Available with three syringe capacities: 100 µl, 500 µl or 1000 µl.

Dosing volumes from 83 nl/pulse.

With a repeatability of < 1% (full stroke).

1/4-28UNF or M6 fluidic connections allow an easy integration.

Specifications

Syringe capacity 100µl | 500µl | 1000µl
Resolution 83 nl/pulse | 415 nl/pulse | 830 nl/pulse
Repeatability CV < 1% (full stroke)
Connection M6 | 1/4-28UNF
Wetted materials Glas, PTFE, PEEK
Fluid temperature range 5 - 40 ° C
Ambient temperature range 5 - 40 ° C
Dimensions 26 x 42 × L120 mm
Motor 2-Phases bipolar stepper motor
Mounting direction Any
