Tubing
Pump head
|
Number
|
Inner-diameter
|
Wall-thickness
|
max. Flow rate
|
Weight
|
|---|---|---|---|---|---|
YZ1515x. YZII15
|
13#. 14#. 19#. 16#. 25#. 17#. 18#
|
0.8 - 7.9 mm
|
1.6. 1.7 mm
|
6.3µl/min - 366 ml/min
|
ca. 5.4 kg
|
YZ2515x
|
15#. 24#
|
4.8. 6.4 mm
|
2.4 mm
|
160µl/min - 266 ml/min
|
ca. 5.4 kg
|
YZII25
|
15#. 24#. 35#. 36#
|
4.8 - 9.6 mm
|
2.4 mm
|
160µl/min - 500 ml/min
|
ca. 5.4 kg
|
FG15-13
|
13#. 14#. 19#. 16#. 25#. 17#. 18#
|
0.8 - 7.9 mm
|
1.6. 1.7 mm
|
5.3µl/min - 400 ml/min
|
ca. 5.3 kg
|
FG25-13
|
15#. 24#
|
4.8. 6.4 mm
|
2.4 mm
|
220µl/min - 366 ml/min
|
ca. 5.3 kg
|
DMD15-13-B
|
2*13#. 2*14#. 2*19#. 2*16#. 2*25#
|
0.8 - 4.8 mm
|
1.6. 1.7 mm
|
13µl/min - 345 ml/min
|
ca. 5.4 kg
|
DG15-24
|
16#. 25#. 17#
|
3.2 - 6.4 mm
|
1.6 mm
|
82µl/min - 300 ml/min
|
ca. 5.8 kg
|
DG15-28
|
13#. 14#
|
0.8 - 1.6 mm ≤3.17mm |
1.7 mm 0.8 - 1.0 mm |
2.0µl/min - 75 ml/min
|
ca. 5.7 kg
|
DG-(1. 2. 4. 6. 8) - 6 Rollen
|
≤3.17mm
|
0.8 - 1.0 mm
|
2.0µl/min - 48 ml/min
|
ca. 5.2 - 5.6 kg
| |
DG-(1. 2. 4) - 10 Rollen
|
≤3.17mm
|
0.8 - 1.0 mm
|
1.5µl/min - 32 ml/min
|
ca. 5.2 - 5.6 kg
|
Specifications pump system
Flow rates
|
0,20µl/min - 380ml/min
|
Speed
|
0.1 to 100 rpm, reversible
|
Speed precision
|
0.1 rpm
|
Speed control
|
Membrane keypad
|
Display
|
3-digit LED displays current rpm
|
Communication interface
|
RS485
|
External control
|
Start/stop, cw/ccw control and speed control 0-5 V, 0-10 V, 4-20 mA and 0-10KHz
|
Power supply
|
AC 100V-240 V 50/60 Hz
|
Power consumption
|
≤20 W
|
Operating condition
|
Temperature 0 to 40°C
|
Relative humidity
|
< 80%
|
Dimensions (L×W×H)
|
232×142×149 (mm)
|
Drive weight
|
2.38 kg
|
IP rating
|
IP 20
|
